15" G15C - 75 Watts

15" G15C - 75 Watts

Impedance
This item is built to order.
Please allow 7-10 business days for your order to ship.

We have created a truly awesome 15" speaker with the G15! Now you can play a 15" with quick, articulate response, aggressive mid-range, & fat low end.

"Man, ever since I received my 15-inch for my Sewell Texaverb, I am totally impressed. I replaced an Eminence Big Ben with your 15. Not as loud now but incredibly spicy.....incredible break-up........sweetness at a lower volume.....I love my WGS."

MOUNTING INFORMATION

  • Diameter 15 3/16"”
  • Overall depth 6”
  • Cut-out diameter 14”
  • Mounting slot dimensions 1/4”
  • Number of mounting slots: 8
  • Mounting slot PCD 14 3/4”

g15c_clean_1-_5-16-12.mp3

g15c_clean_2-_5-16-12.mp3

g15c_dirty_-_5-16-12.mp3

THIELE-SMALL PARAMETERS

Resonant Frequency (Fs):

100.45 Hz

DC Resistance (Re):

6.4 Ohm

Coil Inductance (Le):

8.0 mH

Mechanical Q (Qms):

12.3144

Electromagnetic Q (Qes):

1.188

Total Q (Qts):

1.0835

Compliance Equiv. Vol. (Vas):

2.165 cu ft

Mech. Compliance of Susp. (Cms):

50.169 mm/N

BL Product (BL):

11.64 T-M

Diaphragm Mass Inc. Airload (Mms):

50.0389 grams

Surface Area of Cone (Sd):

923.4744 Surface Area of Cone (Sd):

Sound Pressure Level (spl):

99.03 db

Customer Reviews

Based on 6 reviews
100%
(6)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
J
Jerry Griffin
Great tone

Replaced a JBL D130F in my '64 Vibroverb with this. Nice improvement. Sounds warmer, smoother and more detailed, without sounding shrill like the D130 can with some higher notes. The JBL also sounds a little muddy and fizzy in comparison. The nice, fat bottom end is about the same as the JBL. Overall I'm very happy with it.

g
glenn f
Big 15”

I ordered a 15” ceramic guitar speaker I installed it in a cab and turned it up. At first I was not impressed but as I kept pushing the speaker it got Sweeter and sweeter. You have to brake them in but once you have you will be happy. I think I want the alnico one to pair it with. FYI I like 15”s for guitar.

c
chris bushnell
Peavey Delta Blues sounds Fat now

The stock 15” speaker ( no name, probably Eminence) was functioning but sounded scooped with low mids. The G15C is much fuller and smooth. Big improvement!

J
Jean
Quite a decent sounding 15" speaker

I've building more than a few guitar amps with a number of 15" speakers from '48 to now. this G15C is on my breaking up bench for a few weeks. and, it's getting better day by day.

M
Mont daniel
Review of Mont daniel on 15" G15C Ceramic Speaker - 75 Watts

This speaker frakin Badass! How does it sound with a high gain amp? Dont know, don't care. If you get your overdrive tone the old fashioned way by crankin the shit out of ur amp you will be blown away by this bad boy. Such a sweet top end. Do yourself a favor.
